SS84 SK24 Sk54 SMD Schottky Barrier Diode 1.0a 1000V

Name: SS84 SK24 Sk54 SMD Schottky Barrier Diode 10a 1000V
Brand: trusTec
Price: 1 USD

Buy cheap SS84 SK24 Sk54 SMD Schottky Barrier Diode 1.0a 1000V product

Brand Name : trusTec

Model Number : SS14

Certification : ROHS

Place of Origin : China

MOQ : 7.5K PCS

Price : Negotiable (EXW/FOB/CNF)

Payment Terms : T/T

Supply Ability : 800KK PCS per month

Delivery Time : 10 work days fresh products

Packaging Details : 7.5K PCS per tape&reel, 120K PCS per carton.

Operating temperature : -55°C ~ 150°C

Material : Silicon

Trr : 75ns

Package : SMA

Max. reverse voltage : 1000V

Max. forward current : 1A

Max. forward voltage : 1.7V

Max. reverse current : 5uA

Contact Now

SMD Schottky Barrier Rectifier Diode SS14 SS24 SS34 SS54 SS84 SK14 SK24 SK34 SK54

Product Drawing
SS84 SK24 Sk54 SMD Schottky Barrier Diode 1.0a 1000V
Technical Parameters

Type	Current	Package
SS12D THRU SS120D	1	SOD-123FL
SS22D THRU SS220D	2	SOD-123FL
SS32D THRU SS320D	3	SOD-123FL
SS12F THRU SS120F	1	SMAF
SS22AF THRU SS220AF	2	SMAF
SS32AF THRU SS320AF	3	SMAF
SS52AF THRU SS520AF	5	SMAF
SK12 THRU SK120	1	SMA
SS12 THRU SS120	1	SMA
SS22A THRU SS220A	2	SMA
SS32A THRU SS320A	3	SMA
SS52A THRU SS520A	5	SMA
SK22 THRU SK220	2	SMB
SS22 THRU SS220	2	SMB
SS32B THRU SS320B	2	SMB
SS52B THRU SS520B	2	SMB
SK32 THRU SK320	3	SMC
SS32 THRU SS320	3	SMC
SS52 THRU SS520	5	SMC
SS82 THRU SS820	8	SMC/TO-277

Product Features

The plastic package carries Underwriters Laboratory Flammability Classification 94V-0

For surface mounted applications

Ultra fast switching for high efficiency

Low reverse leakage

Built-in strain relief,ideal for automated placement

High forward surge current capability

High temperature soldering guaranteed 250℃/10 seconds at terminals

Mechanical Data

Case: JEDEC DO-214AC molded plastic body

Terminals: Solder plated, solderable per MIL-STD-750, Method 2026

Polarity: Color band denotes cathode end

Mounting Position: Any

Weight: 0.002 ounce, 0.07 grams

SS84 SK24 Sk54 SMD Schottky Barrier Diode 1.0a 1000V

Product Tags:

1.0a Surface Mount Schottky Barrier Rectifier SS84

SS84 sk24 smd diode

SS84 Sk54 Diode

SS84 SK24 Sk54 SMD Schottky Barrier Diode 1.0a 1000V Images
